.NET Serial Communication and Microbotlabs’ Robotic Claw

Microbotlabs Robotic Claw

Microbotlabs Robotic Claw

I always enjoy playing with electronics and seeing what I can do with them, so I’m a big fan of Arduino and the maker movement. One area I had been wanting to explore with electronics was real world physical interactions, like moving robots or robotic claws. So I added a robotic kit to my wish list on Amazon and just so happened to get one for the holidays!

This is the Microbotlabs “MeArm DIY Robot Arm Kit With MeCon Pro Motion Control Software and Arduino Source Code” that you can get on Amazon MeArm DIY Robot Arm Kit With MeCon Pro Motion Control Software and Arduino Source Code. The kit quality is a little low (especially the servos) and the instructions and support seem lacking; but I was able to put it together and it was still a lot of fun and pretty cool. Once I built the claw, I connected it to my Arduino and tried running the application Microbotlabs include to control the claw from your computer (MeCon).

With everything working, I toyed around with the application for a bit. What I thought was really cool was the idea of “recording” servo positions and playing them back so that the robot could record and playback motions. Below is a screenshot of the application, where you can see the controls. There’s the ability to move the base and each of the 3 servos controlling various parts of the arm, and the on the right there is a list of “coordinates”. These are servo positions, and you can use the application to record a list of these “coordinates” and play them back so that the robotic claw can perform a specified movement (and presumably so you can generate code from it that you can maybe add in your project).

Microbotloabs MeCon application

Microbotloabs MeCon application

This was pretty fun, but it very quickly became obvious it was going to be difficult to record and playback smooth motions without a lot of work. I would record some movements and then I would play the recording back, but the Robotic Claw would jerk and jump to the new servo positions. I was either going to need to record a lot of motion data or just accept jerky movements. Adding insult to injury, it was also difficult to edit a motion once recorded. Here’s a short video of playback of the motion recording with the standard software:

To be fair, I’m sure if I would have spent enough time adjusting and tweaking I could have gotten that to work somewhat, but I still had limitations. I decided it would be fun to build my own interface to address these problems using .NET and very generically called it “Crawl Controller”…

Ta dah!!:

.NET ClawController Application

.NET ClawController Application

Basically, the major feature difference is that a user can move the claw to the desired position and record “key frames” much like 3D animation for 3D models in video games. On playback, the user can have the application interpolate in between each key frame and come up with the “frames” in between so that the motion is nice and smooth. I went ahead and put all my code (which wasn’t the prettiest, but hopefully clear enough) on GitHub so anyone can download and play with it. The application also makes it easier to delete and add new key frames wherever desired which really comes in handy when “designing” a new movement. The application also allows the user to send more precise servo positions rather than just a degree (180 degrees), but the application is still backwards compatible with the code that Microlabs provides out of the box. (See GitHub for Arduino code that allows “Crawl Controller” to use more precise servo positions)

Anyway, here is a video of the finished product with interpolation. It is much easier to put together complex motions and the smooth movement allows much more gentle motions making it easier to pick up and set down objects consistently and repeatedly. Here, I recorded movement for the claw that loops and you can see the claw can repeatedly put down and pick up the VGA/DVI adapter again after finishing the animation without knocking over the adapter- the animation also was easy to record.

Code on GitHub: https://github.com/JhottMaster/ClawController

Hope someone else has as much fun with it as I did.

Exchange Dynamic Distribution Lists

This is another PowerShell script one of my coworkers came up with; it creates dynamic distribution lists. It can be handy to create distribution lists in AD based on location, for example, instead of manually managing a distribution list.


New-DynamicDistributionGroup -Name "123 Building" -RecipientFilter {(RecipientTypeDetails -eq 'UserMailbox') -and (StreetAddress -like "*123 Building*") -and (UserAccountControl -ne 'AccountDisabled, NormalAccount'))}

###

Powershell and AD User Information

Today I was handed a CSV list of AD users and asked to return the list with an “Enabled” column to represent wether a user was enabled or disabled in Active Directory. I used PowerShell to quickly whip this up. For future reference, here is the PowerShell that will take a CSV with a “User” column (that contains the user account name) and generates another CSV with the AD properties desired (in this case enabled, sam account name, and email address).


Import-CSV -Path .\mailbox_access_list.csv | ForEach-Object {
Get-ADUser ($_.User) -Properties Enabled,EmailAddress,SamAccountName | select Enabled,EmailAddress,SamAccountName
} | Export-CSV .\results.csv -NoTypeInformation

### - Pablo Aizpiri

Also, for those times when you quickly need to get users in a AD group using PowerShell…


Get-ADGroupMember [AD Group Name] | select {"[Domain Name]\" + $_.samAccountName}

### - Pablo Aizpiri

Getting emails from a group:


Get-ADGroupMember [AD Group Name] | ForEach-Object {
Get-ADUser ($_.samAccountName) -Properties EmailAddress | select EmailAddress
}

### - Pablo Aizpiri

AD Linked Server Query 1000 Row/Page Limit

Sometimes, you need to dump Active Directory data into a table or view in SQL Server. It is preferable to use a programming interface to do this or tools such as PowerShell. It is easier, less problematic, provides access to array values, and you don’t have to deal with the page limit. However, sometimes you need to do this from SQL Server.

The problem doing this with SQL Server (other than not having access to multi-value properties, dealing with bitwise operations in SQL, and dealing with fragile queries) is that you normally have a row/page limit set on Active Directory of 1000. This can be changed, but it is usually not an option.

Here I provide a SQL solution to get around the 1000 page limit. It generated a temp table that can be queried after retrieving the results from AD. It is not the most elegant, but it works fairly well in only about 20 lines of code. In this case, I’m retrieving all users. Note that a limitation to this query is having over 1000 users whose name (cn) start with the same letter. Usually this is not the case, but if that’s a problem this can be a good jump start.



DECLARE @SYMBOLS AS VARCHAR(128); DECLARE @query VARCHAR(MAX); DECLARE @ADfields VARCHAR(MAX);
SET @SYMBOLS = 'ABCDEFGHIJKLMNOPQRSTUVWXYZ0123456789'; -- AD Search character prefixes used to partition search. (1000 page limit). Below, AD fields to retrieve:
SET @ADfields = 'cn, sAMAccountName, accountExpires, pwdLastSet, userAccountControl, ADsPath, lockouttime, manager, mail, createTimeStamp, employeeID, lastLogon, co, l';
SET @query = 'SELECT * INTO ##tmpAD FROM (';

-- Get each character and for each character construct and AD query:
WITH nmTbl AS (SELECT TOP (LEN(@SYMBOLS)) Idx = ROW_NUMBER() OVER (ORDER BY [object_id]) FROM sys.all_objects ORDER BY Idx)
SELECT @query = @query + 'SELECT * FROM OPENQUERY(ADSI, ''SELECT ' + @ADfields + ' FROM ''''LDAP://DC=newfield,DC=com''''
WHERE objectCategory=''''Person'''' AND (cn = ''''' + SUBSTRING(@SYMBOLS, nmTbl.Idx, 1) + '*'''') AND (objectClass = ''''user'''' OR objectClass = ''''contact'''')'')
UNION
' FROM nmTbl;

-- Finish generating query string:
SELECT @query = LEFT(@query, LEN(@query) - CHARINDEX(REVERSE('UNION'), REVERSE(@query)) - 4) + ') AS qry'

-- Remove temp table if existing before running:
IF OBJECT_ID('tempdb.dbo.##tmpAD', 'U') IS NOT NULL
	DROP TABLE ##tmpAD;
EXECUTE(@query)

SELECT * FROM ##tmpAD


.NET PixyCam Library

Not too long ago I saw a Charmed Lab’s PixyCam project on Kickstarter, and I decided to contribute.

PixyCam

My PixyCam assembled with Pan/Tilt Mechanism

I was really excited about all the possibilities vision can bring to the maker community. I later received the camera, and I have to admit it’s pretty cool. The PixyCam is basically a camera with a micro controller that can be used to tag and recognize colored objects. It can then send this “digested” data back to a micro controller that normally wouldn’t have the processing power to do object recognition. For example, certain colors can be tagged- “signatures”- and the camera can send back through an I2C connection the coordinates and size of one or more rectangles matching this “signature”. And at 50 FPS, there’s some pretty nifty stuff you could do with it, like a robot that follows a ball.

The camera also has two ports to connect two servos that you can control through the I2C connection as well. This makes it easy to quickly get up and going. After assembling mine with a pan/tilt mechanism, I played around with the standard demo program and had fun seeing it “look around” at whatever I had tagged for it to view. Next, I wanted to use it to try out some other ideas, but I wasn’t ready to use it with a micro controller and work on all the programming that goes along with that. Instead, I wanted to quickly use .NET to play around with it. Much to my dismay, I could not find an easy way to do this. Ironically, my desire for an “easy” route led me to build a .NET library. I wanted one and figured others could use it as well.

I’m still working on it but I put together a Visual Studio solution that includes my C# .NET PixyCam library, and the required C++/C projects (only required to generate the DLLs the .NET library uses).

I also included a sample .NET application that uses the library so that it can be easy to get started. The solution and source code can be found on GitHub: https://github.com/JhottMaster/PixyUSBdotNET/tree/master

A couple notes:

1.) Make sure you set a signature if you want the sample application to work. Just fire up PixyMon and tag a color to use as a signature.

2.) Make sure you are using a cable that works (most recommended is under 3 feet) or sends enough power to the servos. I deal with this a lot and it was super frustrating, until I got a cable that could transmit more power over further distances.

3.) The library is a work in progress, keep that in mind. Read the README file for more info.





SSIS Database Security

Generic SQL Security

Quick intro on granting SQL rights in general- I’ve found to quickly setup SQL security I normally use the “db_datareader” and “db_datawriter” roles (assuming entity needs write access) but often times I also need them to be able to execute a stored procedure as well. I don’t want to give them much more access so I find it convenient to just create a “db_executer” role I can assign:

CREATE ROLE db_executor
GRANT EXECUTE TO db_executor



SSIS Security

Anyway, back to the real subject of the post, SSIS- if you have a job you want someone to run from SSIS, they need to have permissions to the SQL SSIS database. Usually I don’t want to manage individual permissions at the user level in SQL server, so a popular options is to create an AD group and grant that AD group access to the SSIS database as needed. Then one only needs to manage the AD group. More on SSIS security here.

Recently, we had a situation where we had a report that fired off a store procedure that submitted an SSIS package, waited for it to finish, and returned the results. (here’s how) We were using windows authentication which wasn’t optimal because we had to grant that group/users access to the SSIS database- and plus we had to update security in two places, the SQL SSIS database and the SSRS report.

For this situation, creating an AD group that was used by both SSRS and SSIS didn’t make sense because they would both likely diverge at some point, but mostly we didn’t want to provide those users access to log into the SQL database. So instead we created a single user account that the SSRS data source could use to connect to the SQL server- then we can just control access to the report from SSRS security. By the way, one caveat to this method is that the account can’t be SQL account- it has to be Windows authenticated account in order to run the SSIS package[s].



Removing SQL Users from SSIS Database

Anyways, after I did that I decided to clean up the database but found I couldn’t delete the users from the SSIS database; I got an error that dropping the user failed:

Msg 27226, Level 16, State 1, Procedure ddl_cleanup_object_permissions, Line 16
The database principal has granted or denied permissions to catalog objects in the database and cannot be dropped.
Msg 3609, Level 16, State 2, Line 1
The transaction ended in the trigger. The batch has been aborted.

I quickly unchecked all the database role memberships but still couldn’t drop the user. I ended up going through a series of steps with some valuable queries that I wanted to share for future debugging. First, I looked at the permissions assigned to the user:

SELECT *,
object_name(major_id) as securable,
user_name(grantor_principal_id) as grantor,
user_name(grantee_principal_id) as grantee
from sys.database_permissions
where grantee_principal_id = user_id('[DOMAIN]\[USERNAME]')

At this point this only showed the “CONNECT” priviledge, which I was able to revoked:

REVOKE CONNECT TO [DOMAIN\USERNAME]

Now as far as I could tell my user didn’t have any rights but I still got the same errors. I should have paid more attention to the error message- particularly the part about a trigger. This is a trigger in the SSIS database that fires off when dropping a user that has SSIS catalog permissions. SSIS has its own permissions layer and those permissions needed to be revoked in order to remove the user. SSIS catalog permission information on users can be found in
[SSISDB].[catalog].[explicit_object_permissions] table.
I found a handy query for querying this information and generating the SQL to revoke the permissions using
catalog.revoke_permission
here:

SELECT TOP 1000 [object_type]
       ,[object_id]
       ,[principal_id]
       ,[permission_type]
       ,[is_deny]
       ,[grantor_id]
    , 'EXEC catalog.revoke_permission @object_type=' + CAST([object_type] AS VARCHAR)
          + ', @object_id=' + CAST([object_id] AS VARCHAR)
          + ', @principal_id=' + CAST(principal_id AS VARCHAR)
          + ', @permission_type=' + CAST(permission_type AS VARCHAR)
   FROM [SSISDB].[catalog].[explicit_object_permissions]
   WHERE principal_id = USER_ID('Your User')

Nobody Cares Why

The other day we had a bug in one of our applications that prevented users from using certain symbols when saving “document” objects in the application. I got a ticket about the bug, so I looked into it and realized when the application was saving the “document” object to the database it would first attempt to write the file on a filer and this is what was failing- the illegal characters were an illegal Windows file name, and when writing to the filer this was failing.

So I call up the user and shared with them the problem- when the document is being saved, the file included is also saved and the characters in the name are illegal file names. “You know- like when you save a file on your desktop and you include a backslash or something”. The user had an “Ah! Yeah, I understand” moment when it immediately made sense with their own experience of using Windows.

Anyway, later I was thinking about why did I do that? Why did I have to explain to the user why their action didn’t work?

Nobody cares why it didn’t work.

Nobody cares about some artificial (as far as the user is concerned) Windows “limitation” on how the file is “supposed” to be named. It should just work.

Usually I am pretty good about thinking from the user experience perspective; yet here I caught myself forgetting for a moment and with developer tunnel-vision. I may care about why it doesn’t work- I need to most of the time- but nobody else does, and they shouldn’t.

On a slightly unrelated note, user interfaces often suffer from developer’s view of the world. I recently heard a quote I liked regarding user interface design: “The user interface is like a joke- if you have to explain it, it’s not that good”.

Executing an SSIS package from Stored Procedure

I recently needed to do this for a report. In theory, the SSIS package was going to run on some sort of schedule, but then it was decided that the user wanted the ability to run the report on-demand. Since the SSIS package didn’t take too long to execute, I decided I would try to run it on-demand. I was using this in an SSRS report, so I had to build a stored procedure to do this.

The key here is that I had to run the SSIS package, wait until the package was done, and then return data. I also didn’t want the package to potentially run indefinitely, and so if a package ran longer than the timeout or the job ran into an issue, the report should return empty.

NOTE: Make sure the user that will run the procedure also has access to run the SSIS package. (This is granted by giving user access to SSIS database; more here)

This is what I came up with which ended up working rather nicely:

-- =============================================
-- Author:		Pablo Aizpiri
-- Create date: 7.15.2015
-- Description:	Runs the SSIS package that returns results
-- results
-- =============================================
ALTER PROCEDURE [dbo].[RefreshAndQueryFromSSIS]
	@TIMEOUT_SECONDS INT = 60 -- Max number of seconds to wait for SP to execute.
AS
BEGIN
	-- SET NOCOUNT ON added to prevent extra result sets from
	-- interfering with SELECT statements.
	SET NOCOUNT ON;

	DECLARE @EXECUTION_ID BIGINT, @OUTPUT_EXECUTION_ID BIGINT

	-- Setup SSIS package to run:
	EXEC SSISDB.CATALOG.CREATE_EXECUTION
						@FOLDER_NAME = '[SSIS Package Folder Name]'
						,@PROJECT_NAME = '[SSIS Project Name'
						,@PACKAGE_NAME = '[SSIS Package .DTSX File Name]'
						,@EXECUTION_ID = @EXECUTION_ID OUTPUT

	-- Run SSIS package:
	EXEC SSISDB.CATALOG.START_EXECUTION @EXECUTION_ID
	SET @OUTPUT_EXECUTION_ID = @EXECUTION_ID;

	DECLARE @STATEID AS INT = 0, @SECONDSRAN AS INT = 0
	-- Waits until package is successfully completed or until max timeout is reached:
	WHILE (@STATEID < 3 OR @STATEID = 5) AND @SECONDSRAN < @TIMEOUT_SECONDS
	BEGIN
		WAITFOR DELAY '00:00:00:5'; -- Give time back to CPU while waiting for timeout
		SELECT @STATEID = status, @SECONDSRAN = DATEDIFF(SECOND, start_time, GETUTCDATE())
		FROM SSISDB.catalog.executions
		WHERE execution_id = @EXECUTION_ID;
	END

	SELECT *
	FROM [Results table here]
	WHERE @STATEID = 7 -- this ensures results are only returned if the package execution was successful.
END

SQL Troubleshooting Queries (2)

Found this MSSQL query on StackOverflow for troubleshooting locks or not being able to access a database being taken offline.. posting for self-reference:

SELECT
        DB_NAME(l.resource_database_id) DB,
	l.resource_type,
	l.request_mode,
	l.request_status,
	l.request_session_id,
	r.command,
	r.status,
	r.blocking_session_id,
	r.wait_type,
	r.wait_time,
	r.wait_resource,
	request_sql_text = st.text,
	s.program_name,
	most_recent_sql_text = stc.text
FROM sys.dm_tran_locks l
LEFT JOIN sys.dm_exec_requests r
	ON l.request_session_id = r.session_id
LEFT JOIN sys.dm_exec_sessions s
	ON l.request_session_id = s.session_id
LEFT JOIN sys.dm_exec_connections c
	ON s.session_id = c.session_id
OUTER APPLY sys.dm_exec_sql_text(r.sql_handle) st
OUTER APPLY sys.dm_exec_sql_text(c.most_recent_sql_handle) stc
--WHERE l.resource_database_id = DB_ID('[Database Name]')
ORDER BY request_session_id;

Some additional helpful links:
Lock Modes
Wait Types; Additional wait Type Info
Locks System Table Info

Also, connection by session:

SELECT * FROM SYS.DM_EXEC_CONNECTIONS WHERE SESSION_ID = [SESSION ID]

SQL Troubleshooting Queries (Locks)

Some helpful queries used to do lock/running query diagnosis.

sp_who and sp_who2 system stored procedures returns some helpful information for diagnosing current connections; but it’s hard to filter. Here’s a quick query for dumping the results into a temp table for filtering. The key field is “status” to help you determine if the connection is hung.

DECLARE @Table TABLE(
        SPID INT,
        Status VARCHAR(MAX),
        LOGIN VARCHAR(MAX),
        HostName VARCHAR(MAX),
        BlkBy VARCHAR(MAX),
        DBName VARCHAR(MAX),
        Command VARCHAR(MAX),
        CPUTime INT,
        DiskIO INT,
        LastBatch VARCHAR(MAX),
        ProgramName VARCHAR(MAX),
        SPID_1 INT,
        REQUESTID INT
)

DELETE FROM @Table
INSERT INTO @Table EXEC sp_who2

SELECT  *
FROM    @Table
WHERE DBName --...

In my case, we discovered it was a SQL Server Agent connection and it was running a job that was hanging. Some additional helpful queries to answer What is the Job Id? What are the current job statuses?

SELECT *
FROM msdb..sysjobs s
LEFT JOIN master.sys.syslogins l
      ONs.owner_sid = l.sid

EXEC msdb.dbo.sp_help_job @Job_name = '[..]'

Stop a job:

EXEC msdb.dbo.sp_stop_job @Job_name = '[..]'

Finally, a query to request last time a stored procedure was changed:

SELECT *
FROM sys.objects
WHERE type = 'P'
AND NAME = '[Stored Procedure Name]'
